Status: under construction. This README describes only what is on disk. Everything marked planned is specified in the v2 build plan and does not exist yet. BigLaw 1 (the DyTopo platform) is frozen on the branch
archive/v1-final(a branch, because tag pushes are blocked in the build environment).
Start here. To use BigLaw (install it, add a matter's documents, ask a question, review and
download the memo), read the user guide: plain words, no programming. To
work on BigLaw, read on: this README is the contract for what is on disk, docs/ holds the design
(§ Architecture and patterns), and CLAUDE.md holds the rules every change follows.
BigLaw 2 will be a legal AI workbench for small firms: memos, contract review and diligence
tables in which every factual statement cites a quote that the software has verified against the
matter's own documents, with a lawyer approving every deliverable. It is one Go binary plus one
PostgreSQL database. Licensed Apache-2.0 (LICENSE, NOTICE).
For running BigLaw on your own computer. Install Docker Desktop and start it, then paste this into a terminal (macOS Terminal, Linux, or WSL on Windows):
curl -fsSL https://raw.githubusercontent.com/discover-legal/BigLaw/main/setup.sh | bashIt asks one question: your OpenRouter API key, or Enter to use
Ollama on this computer (ollama pull qwen2.5:14b and nomic-embed-text
first). It then starts BigLaw, reachable only from this computer, at http://127.0.0.1:3101.
Its files are in ./biglaw: the settings (.env, readable by you alone; edit it to change
models, § Configuration) and the Compose file. Run the same command again to update; your
settings and documents are kept. setup.sh is about 60 lines (read it first if you
like; SETUP_REF=<branch or tag> downloads the Compose file and .env.example from there). On
Linux, Docker reaches an Ollama on the host only if Ollama listens beyond 127.0.0.1 (e.g.
OLLAMA_HOST=172.17.0.1, Docker's bridge).
| Piece | Path | What it does |
|---|---|---|
| Command | cmd/biglaw/main.go |
biglaw serve [--allow-no-auth] [--admin-without-auth] (migrates the database, then serves the API and the embedded UI and runs tasks) and biglaw version [--config] |
| Configuration | cmd/biglaw/config.go |
Declares all 18 runtime variables (BIGLAW_MODELS is the role map); validates the ones this build reads (all problems at once); vendor breakers ported from v1 |
| Store | internal/store/store.go |
Postgres via database/sql + github.com/lib/pq; DSN check that matches lib/pq's reading; transaction helper |
| Migrations | internal/store/migrate.go, internal/store/migrations/NNNN_*.sql |
Embedded SQL files applied in order under an advisory lock; each file and its schema_migrations row in one transaction. store.Open first creates the vector extension (pgvector), which is database-wide (§ Database) |
| Files | internal/store/files.go |
Binary files (uploads, generated .docx) stored in 1 MiB bytea chunks, streamed in and out, with size and SHA-256 checked on every read |
| Model client | internal/model/ (client.go, embed.go, errors.go, fake.go, pricing.go, prices.json) |
One OpenAI-compatible chat client with tool calls and image parts, an embeddings call (Embed) on the same transport, typed failures, at most 3 attempts per call, cache-aware pricing of every call from a built-in table plus BIGLAW_PRICES (the host never makes a call free), watt-hour metering when BIGLAW_LOCAL_WATTS is set, and model.Fake for tests (§ Model client). Embed's caller is documents (below); Chat's is the agent loop (below), which the memo workflow drives. |
| Documents | internal/docs/ (ingest.go, child.go + child_linux.go/child_other.go, pageindex.go, chunk.go, search.go, embed.go, verify.go, http.go, vision.go + vision_prompts.txt, scanpdf.go, jobs.go) |
Ingest of UTF-8 text (a plain-text e-mail whose headers say quoted-printable is stored decoded, headers verbatim: TestEmailBodyDecodedFromQuotedPrintable), .docx and PDF text layers (PDFs and .docx files parsed in a bounded child process); images and JPEG-scanned PDF pages transcribed by the vision role, each page read twice and the readings compared, with provenance on every document, chunk and citation, and a leased job that transcribes what was stored before a vision role was set (§ Vision transcription); the byte-exact section tree; search chunks; Postgres full-text search, fused with pgvector similarity when an embed role is set (chunk embedding at ingest, a startup backfill); the page reader (outline, paged sections); the quote-verification ladder; the upload and download routes. Every read is scoped to the caller's document ids (§ Documents) |
| Agent runtime | internal/agent/ (tool.go, registry.go, schema.go, loop.go, budget.go, policy.go, bandit.go) |
The Tool interface and its single registry (definitions frozen at registration), JSON-schema validation of every tool input and output, one bounded loop for the lead and its subagents, the budget ledger, and the tool bandit (§ Agent runtime). The memo workflow drives it (below); a step log makes it resumable |
| Engine | internal/engine/ (+ specs/, packs/; migrations 0005_runs.sql, 0006_figure_reads.sql, 0007_figure_reads_scope.sql) |
The memo workflow: the lead agent and its 12 tools, the ledger, the evidence subagents with Go-side quote verification, the figure reader, the sweep, the three-critic committee, the policy, finish (lint, coverage, render), the human gates, grounding collapse, and durable runs (step log, lease and heartbeat, resume) (§ Memo workflow) |
| API | internal/api/ (+ dist/, the embedded UI) |
The REST API (tasks, steps, SSE events, gates, cancel, cost, clients, Manage: manage.go) over the engine and the document routes, and the web UI built into the binary (§ Memo workflow, § Manage) |
| Manage | internal/engine/specset.go, manage.go, manage_validate.go, diff.go, skills.go, custom.go, remote.go, hookrules.go (+ skills/, specs/use_skill.json; migrations 0008_overrides.sql, 0009_custom_tools.sql, 0010_secret_origin.sql), internal/api/manage.go, ui/src/screens/Manage.tsx |
The catalogue of every agent, tool, pack, skill and hook a run uses, admins' versioned overrides in Postgres (strictly validated, compatibility-checked against what Go reads and writes), each task's snapshot of them, history, diffs, revert and a patch/zip export; skills and use_skill; admins' own subagents and MCP/HTTP tools with SSRF-checked calls and server-side secrets, a metered Test call, and configurable hooks around calls, findings and finish (§ Manage) |
| Memo tools | internal/analysis/ (+ belo.json, specs/*.json), internal/docs/register.go (+ specs/*.json) |
Deterministic tools over verified findings: numbers (exact calc, figure handles, key-figures table), join_discrepancies, the coverage checks finish{op:"check"} will run, the value normalisers and BELO-lite; and the retrieve / verify_quote adapters over documents (§ Agent runtime) |
.docx reader |
internal/docs/ooxml/ |
Opens a .docx's text parts only (body, footnotes, endnotes; 128 MiB decompression cap) and reads its visible text in one linear XML pass. The writer, the XML escapers, the part-preserving re-zip and tracked-change parse/apply are planned (PR 3d) |
| Evaluation | eval/ (run.py, proofrun/, lab/, tests/, tasks/, e4/embeddings.json) |
The five synthetic proof-run matters (documents + answer keys), copied from feat/proof-runs-multi-practice, with their driver and scorer (run.py), the Harvey LAB driver (lab/run.py), and the Go gates E1/E2 that run them through the engine on a scripted model (§ Memo workflow). eval/e4/embeddings.json is E4's embeddings tape: today the self-test tape of a hash embedder, not a real model's (§ Documents, gate E4) |
| UI | ui/ (React 19 + Vite + TypeScript strict; runtime deps react, react-dom only) |
Matters, Documents, Task and Manage (§ UI) behind one transport seam, ui/src/api/transport.ts: http.ts talks to the Go API on the same origin (tasks, steps, findings, gates, cost and documents are served since PR 4b), recorded.ts replays a recorded engine in the browser with no network at all |
| Recorded demo | ui/src/recorded/recording.json, eval/demo/record_test.go |
Three synthetic matters (13 documents plus one scanned exhibit, ui/src/recorded/06-affidavit-of-service-scan.jpg, drawn by eval/demo/make_scan.py) and seven recorded memo tasks (48 findings, 79 citations); documents, outlines, sections, chunks, the scan's transcript (v2's vision path with a scripted reader), run-log and offered search hits and every quote's verification computed by v2's internal/docs; claims from the answer keys; the default call budget read from cmd/biglaw/config.go (§ UI, provenance). TestDemoRecording fails when the committed recording no longer matches what v2's code computes |
| Sign-in | internal/auth/ (oidc.go, session.go; migration 0011_sessions.sql), internal/api/signin.go; 0012_task_submitter.sql |
OpenID Connect code flow with PKCE against one issuer, ID tokens verified with the standard library (discovery, JWKS, RS/ES signatures, claims), server-side sessions behind an opaque cookie, admins by BIGLAW_ADMINS, and the API behind a session (§ Sign-in) |
| Test helper | internal/auth/authtest/ |
A local OpenID provider (httptest: discovery, JWKS, PKCE-checking token endpoint, RSA and EC keys, key rotation) and the helpers to craft refused tokens and walk a browser through sign-in |
| Test helper | internal/store/storetest/ |
Gives each DB test its own schema; skips without a DSN, fails if BIGLAW_REQUIRE_DB is set |
| Test helper | internal/engine/figtest/ |
The figure reader's stand-in for tests (figtest.Reader, a model.Fake Respond hook): labels plain fixture texts so tests not about figure reading run unscripted (engine, API and eval tests) |
| Budgets | scripts/loc.py (+ scripts/test_loc.py) |
Fails CI if a size budget is exceeded (below) |
| Build/deploy | Makefile, Dockerfile, docker-compose.yml, render.yaml, .env.example, setup.sh |
the one-command installer (§ Install; TestSetupScriptMatchesRepo); make ci (and the owner-run make e4-record / make e4-live); pgvector/pgvector:0.8.6-pg16 + biglaw under Compose; Render blueprint (inert until sign-in is configured, see § Exposure) |
| CI | .github/workflows/ci.yml |
make ci against pgvector/pgvector:0.8.6-pg14 and :0.8.6-pg16 service containers (pinned by digest) with BIGLAW_REQUIRE_DB=1; staticcheck, shellcheck + govulncheck; image build + Compose smoke test; on a push to main (:latest) or a v* tag (:X.Y.Z), once all jobs pass, the image is pushed to ghcr.io/discover-legal/biglaw |
HTTP surface today: the REST API of § Memo workflow, the embedded UI at /, and GET /health, which returns {"status":"ok","version":"…","search":"hybrid"} (200;
"search":"lexical" when BIGLAW_MODELS has no embed role) or
{"status":"database unavailable",…} (503; the cause is logged, not returned). Every other path
is 404/405. With sign-in configured (§ Sign-in) every route but /health, the UI's files and /auth/* needs a session; without it there is no authentication (§ Exposure).
Planned (not built): the .docx writer and tracked-change parse/apply (PR 3d); diligence (PR 5), contract review (PR 6),
MCP (PR 7), clients/conflicts and API tokens (the rest of PR 8; OIDC sign-in and sessions are built, § Sign-in), time and billing (PR 9), the
full jurisdiction and practice pack catalogue (PR 12; four candidate packs ship with PR 4b), v1 import and docs (PR 13). The
discover.legal intake module is not part of v2 (owner decision; it moves to a separate repo).
This README is the contract. The design is described in docs/:
docs/architecture.md: the packages and the import rules the tests enforce, a task's lifecycle from submission to the rendered memo, the budget, meter and journal, the spec set and snapshot, the figure pipeline, hooks, and custom tools. Each part links to the code that implements it.docs/patterns.md: the recurring patterns (typed tool specs, Go checking model output, fail closed or disclose, unclear gates, journaled steps, budget shares, content-hash caches, versioned overrides, admin-guarded writes, untrusted-text labelling) and the test patterns. For each: why it exists, and how to apply it.docs/glossary.md: the project's vocabulary and the ledger kinds. The G1–G11, P1–P9 and E0–E4 codes this README uses throughout are defined in its Codes table.docs/documents.md,docs/figures.mdanddocs/reference.md: the design detail this README leaves out (documents, search and vision transcription; the figure rules; the model client, agent runtime, memo workflow, Manage and hooks in depth).docs/benchmarks.md: the pinned benchmark suite (make bench), its results schema,compare.pyand the baselines.docs/user-guide.md: BigLaw for a lawyer, in plain words.docs/consolidation-proposals.md: the consolidation items still open for the owner's decision.
TestDocsCiteRealTests fails when this README, CLAUDE.md or a page in docs/ names a Test…
that the code does not define.
Environment variables only. All 18 are declared in cmd/biglaw/config.go, each in the PR that
first reads it. biglaw version --config prints every value and exits nonzero if what this build
reads is invalid. biglaw serve warns about any unknown BIGLAW_* name (likely a typo).
What may be printed follows one rule, used by version --config and by every startup error:
whatever does not parse into a shape known to be safe is not shown.
- Secrets (
BIGLAW_MODEL_KEY,BIGLAW_OIDC_CLIENT_SECRET): set/unset only. BIGLAW_DATABASE_URL: onlyhost,port,user,dbnameandsslmodeas lib/pq itself parses them (PG*defaults included), whether a password is set, and a count of other parameters. Nothing is copied from the DSN text, so no quoting in it can expose part of a password. A DSN that fails its check is not shown at all.- URL variables (
BIGLAW_MODEL_URL,BIGLAW_PUBLIC_URL,BIGLAW_OIDC_ISSUER): onlyscheme://host[:port], never the path, query or fragment, and only for an absolute http(s) URL whose host is a plain ASCII name or IP and which has no@anywhere. Everything else (no scheme, a typo such ashttps:/, user info, an IPv6 zone id) prints as "(set, not shown …)". The@rule matters because an unescaped/,?or#in user info makes Go read part of the credential as the host and the rest as the path. The host is shown, so never put a key there. A Compose service name with_is a plain host. BIGLAW_MODELS: shown as set only if every entry parses asrole=<model id>with a safe id (below); otherwise "(set, not shown …)". A value that does not parse is never shown; a well-formed id is shown and logged as written, so ids shaped like a key are refused (below).- Anything else is shown as set (quoted, with escapes, if it holds a control or other
non-printing character such as a bidi override or a zero-width space, so it cannot forge or
disguise an output line), unless it contains
://(then treated as a URL) or has theuser:password@shape (then not shown).
| Variable | Default | Meaning |
|---|---|---|
BIGLAW_DATABASE_URL |
— (required) | Postgres DSN: postgres://user:password@host:5432/db?sslmode=disable, or libpq key=value form. The scheme must be lowercase, and reserved characters in the password percent-encoded (/→%2F, ?→%3F, #→%23, %→%25, @→%40). An @ after the host (in the database name or a query value such as application_name=ops@corp) is refused too, because it cannot be told apart from a broken password; write %40. Anything else is refused with a message that never shows the password. lib/pq defaults to sslmode=require. |
BIGLAW_ADDR |
127.0.0.1:3101 |
Listen address. Non-loopback needs serve --allow-no-auth (§ Exposure). |
BIGLAW_PUBLIC_URL |
http://127.0.0.1:3101 |
How browsers reach BigLaw, https://host[:port] with no path: the redirect URI is <it>/auth/callback, https makes the cookies Secure and __Host-, and its host is the one DNS name served under sign-in. Read only with sign-in, which refuses plain http except on loopback |
BIGLAW_MODEL_URL |
— | OpenAI-compatible API base, ending in its version (http://localhost:11434/v1); calls go to <URL>/chat/completions and <URL>/embeddings. http(s), a plain ASCII host with at least one letter or digit, a port up to 65535, no @ anywhere (no credentials in the URL; write any other @ as %40). Required when the key or a role is set. |
BIGLAW_MODEL_KEY |
— | API key for that URL, sent as Authorization: Bearer; no white space or control characters. serve warns if it would go over plain http. |
BIGLAW_MODELS |
— | Model id per role, as the endpoint names it: comma-separated role=id, roles lead, specialist, critic, vision, embed, each at most once (e.g. lead=qwen2.5:14b,critic=glm-4.5-air,embed=nomic-embed-text). Unset specialist or critic use the lead's; setting either without the lead is refused. vision and embed have no fallback: with no embed role search is lexical only (/health says "search":"lexical"); vision names the model images and scanned pages are sent to; without it they are stored as needs_transcription (503 vision_not_configured) and never sent to another role's model (§ Vision transcription). An unknown role, a repeated one, an empty id, an id over 200 bytes, or an id holding ://, user:password@, white space, a control or invisible (format) character, ? = &, or a key's shape (sk-, sk_, AKIA, ASIA, AIza, xox?-, gh?_ prefixes, or 24 letters and digits in a row) is a startup error that does not echo the value. A wrong id fails at its first call with 404 → model_not_configured; with no lead, chat calls fail with 503 model_not_configured. |
BIGLAW_BUDGET_CALLS |
400 |
Model calls per task, lead turns included (at the first bench's $0.012–0.020 a call, 400 calls cost $4.80–8.00, so the default $5 usually binds first; every share holds on both) |
BIGLAW_BUDGET_USD |
5 |
Dollar cap per task |
BIGLAW_LOCAL_WATTS |
— | Power draw of the machine running the model; when set (above 0) every call records watts × duration as watt-hours, an estimate shown in the Task screen's Cost tab (never a price). A number from 0 to 100000 |
BIGLAW_PRICES |
built-in | Model rates overriding the built-in table: the JSON itself (a value starting with {) or a path to a regular file of at most 1 MiB holding it (§ Model client) |
BIGLAW_COLLAPSE_THRESHOLD / _ACTION |
0.5 / strict |
Grounding-collapse policy |
BIGLAW_OIDC_ISSUER |
— | Turns sign-in on: the issuer's https URL exactly as its discovery document states it (https://idp.example.com/realms/biglaw), no query; plain http only on loopback (§ Sign-in) |
BIGLAW_OIDC_CLIENT_ID / _CLIENT_SECRET |
— | The OIDC client, set with the issuer (the secret is optional: a public client uses PKCE alone); no white space |
BIGLAW_ADMINS |
— | Sign-in's admins: comma-separated entries, each a verified email (has an @, case-insensitive, matched only when the ID token's email_verified is true) or an issuer subject (sub, exact). Everyone else who signs in is a member. Refused without sign-in |
ALLOW_ANTHROPIC |
off | Opt in to a direct anthropic.com model endpoint (vendor breaker) |
ALLOW_AWS |
off | Opt in to a direct AWS/Bedrock model endpoint (vendor breaker) |
Tests use two more: BIGLAW_TEST_DSN and BIGLAW_REQUIRE_DB (turns a skipped DB test into a
failure). TestEnvVarTablesAgree fails if this table or docker-compose.yml lacks a variable
config.go declares, if .env.example or render.yaml sets other than its fixed list (the
model URL/key/models, the OIDC variables and BIGLAW_ADMINS; Render adds the database URL and address), or if any
of these files names a variable config.go does not declare.
libpq variables. lib/pq also reads the standard libpq PG* variables (PGHOST, PGPORT,
PGUSER, PGPASSWORD, PGSSLMODE, PGPASSFILE, …) as defaults for anything the DSN leaves
out, and refuses to start if one it does not support (such as PGGSSENCMODE) is set. They are
outside the 18-variable surface; version --config lists the names it sees, never their values.
Compose uses PGPASSWORD on purpose (§ Run it).
Vendor breakers. Ported from v1 biglaw-go/internal/config/guard.go: a BIGLAW_MODEL_URL
containing anthropic.com refuses to start unless ALLOW_ANTHROPIC is 1/true/yes/on; one
containing amazonaws.com or bedrock refuses unless ALLOW_AWS is. Matching is
case-insensitive, on the whole URL, and a non-ASCII host is refused (write it in xn-- form), so
look-alike dots such as 。 cannot slip past; Go's URL parser already refuses %-escapes such as
%2E in an ASCII host. A Claude model behind
a third-party gateway (OpenRouter, LiteLLM) is allowed.
internal/model is the only code that talks to a model. It speaks the OpenAI chat-completions
protocol with native tool calls, so one client serves Ollama, LM Studio, vLLM, GoFetch,
OpenRouter, LiteLLM or a cloud vendor's compatible endpoint. No test calls a real model: every
caller is tested against model.Fake or an httptest server.
-
Requests and answers: text and images (base64
data:URLs only, so the endpoint never fetches a URL on BigLaw's behalf) in, text and/or typed tool calls out; a malformed tool call fails the call, a refused-but-billed answer still reports its usage, and redirects are never followed: docs/reference.md § Model client. -
Failures are typed (G6); the API sets the status,
errorTypeand BigLaw's fixed message from the kind (engine.ErrorType; the document routes:docs.writeError):Kind When HTTP errorTypeErrNotConfiguredno URL, no model for the role, 401/403/404 (a missing or refused key, a wrong base URL or model id: one hint names all three) 503 model_not_configuredErrRateLimited429 after the last attempt ( (*model.Error).RetryAfteris the provider'sRetry-After, at most 24 h)503 model_rate_limitedErrUnavailable5xx after the last attempt, another 4xx (400/413/422 included, see Limitations), a redirect (never followed), an unreachable endpoint, an answer over 32 MiB or not in the chat-completions shape, a malformed tool call 502 model_unavailableErrTimeoutthe caller's deadline, or no answer within the 5-minute client timeout 504 model_timeoutErrNoContentno choice, or a choice with neither text nor tool calls 422 no_content(cancelled) the caller cancelled 499 — Anything else is a 500. Error text holds only BigLaw's own fixed words and the status code: never the endpoint URL, host or port, the key, or anything the endpoint sent. A transport failure is one of "connection refused", "DNS lookup failed", a timeout, or "the connection failed or the answer is not valid HTTP" (Go's own error text can quote the bytes a server sent). Role ids (
BIGLAW_MODELS) reach the logs as written, so startup refuses an id that holds://,user:password@, white space, a control or invisible character (a bidi override could disguise a log line),?,=or&(a query string such asgw.example.com/v1?key=…could carry a key), or has a key's shape (vendor prefixes, 24 letters and digits in a row; a heuristic: a key in another shape is shown), and never echoes it (TestRoleIDRefusesQueryCharacters); soname:tag@quantis refused too, while LM Studio'sname@quant, Ollama'sname:tag, OpenRouter'svendor/modeland Bedrock-styleus.anthropic.…-v1:0are fine. -
Retries. At most 3 attempts per call, only after 429, 500, 502, 503, 504 or 529. The wait is the provider's
Retry-Afterin seconds, or 1 s then 2 s plus up to 25% jitter. ARetry-Afterover 30 s (however large: values past int64 too), or a wait that would outlast the caller's deadline, ends the call at once with the last error. Network errors are not retried (the request may already have been billed). -
Pricing. Every call is priced from the price table (
internal/model/prices.json, overridden byBIGLAW_PRICES), whatever the endpoint's host: a local endpoint is not free (owner decision). A model with no row or anullrow has an unknown cost (nil), never $0. A model you really run for free is set to zero explicitly:BIGLAW_PRICES='{"qwen2.5:14b": {"in": 0, "out": 0}}'.servelogs each role's price once at startup. The format, the matching rules and the built-in rows: docs/reference.md § Model client. -
Embeddings and watt-hours.
Embed(up to 256 texts a call on theembedrole's model) has the chat call's retries, redirect rule, typed failures and pricing; noembedrole is 503model_not_configured. WithBIGLAW_LOCAL_WATTSset every call also records estimated watt-hours, never changing its price: docs/reference.md § Model client. -
model.Fakeanswers from scripts keyed by agent name, in order. A call for an agent with no script, or past the end of its script, is an error, never a default reply; an empty reply isErrNoContentand a malformed tool callErrUnavailable, as from the real client; tool-call ids it fills in are<agent>-<call>-<index>(the agent's own call count), so runs are deterministic. It does not resolve roles: a request'sRoleonly names its reply's model (fake:<role>).Fake.Embedanswers from aVectors(text)function (unset: an error, never a default vector), checks requests as the client does and records them (EmbedCalls).Fake.Route, when set, names the script a request is answered from (by what it holds), so calls that arrive in any order (a parallel sweep's visits) get their own replies (TestFakeRouteAnswersByContent).
Without sign-in there is no authentication, so biglaw serve refuses to listen on a non-loopback
BIGLAW_ADDR (anything but 127.0.0.0/8, ::1 or localhost) unless sign-in is configured
(§ Sign-in) or it is started as biglaw serve --allow-no-auth. That flag means: something outside
BigLaw limits who can reach the port. With sign-in configured, --allow-no-auth has no effect
(serve logs that it is ignored, so Compose's command works unchanged) and --admin-without-auth
is refused at startup (admins are BIGLAW_ADMINS; a flag that made everyone an admin cannot
coexist with sign-in). Without sign-in both behave exactly as before. The deploy files follow the
rule, and TestDeployFilesFollowExposureRule keeps them that way:
- Compose listens on
0.0.0.0inside the container, publishes the port on the host's127.0.0.1only, and passes--allow-no-auth. Do not publish it on0.0.0.0or a LAN address. With sign-in, put a TLS reverse proxy on the host in front of127.0.0.1:3101(§ Sign-in). The test reads every published port andnetwork_modeof every service, in every profile, from whatdocker compose --profile '*' config --no-interpolateresolves at the repo root (asdocker compose upwould, override files included). Each port must name a loopback IP; an interpolated host (${BIND:-127.0.0.1}:…) is refused because the environment could change it. Any Compose file besidesdocker-compose.ymlat the root (compose.yaml,docker-compose.override.yml, …) fails the test. It needsdocker: without it the test is skipped, and fails whereCIis set, likemake compose-check.TestComposeExposureCheckCatchesBypassesruns it on the spellings the review committee used to get past earlier checks. - The image's default command is plain
serve, sodocker run -p …or any platform that exposes the container refuses to start unless sign-in is configured. - Render is public by nature, so
render.yamlis inert until its OIDC variables are set in the dashboard: until then the service fails its start on purpose. SetBIGLAW_PUBLIC_URLto the service's https URL with them: with it left at its loopback default the service starts, but no sign-in can complete (it fails closed). - Manage under
--allow-no-authis read-only (without sign-in). Reaching the port is not proof of being an admin, and an edit in Manage changes every later task of every matter, so with--allow-no-authnobody may edit there (403forbidden; the screen says why). An operator who accepts that anyone who can reach the server may change its agents, tools, packs and skills passesserve --allow-no-auth --admin-without-auth(serve logs a warning; the screen shows a banner). Compose keeps["serve", "--allow-no-auth"]: to edit in Manage under Compose, configure sign-in, or add"--admin-without-auth"to the service'scommandin a local copy, knowing what it allows. A loopback server started without either flag (local development) is an admin. - Gates without sign-in have no identity. Anyone who can reach the API can approve or reject a
gate: the deliverable's, a finding's, or a configurable hook's approval, and the decision records
the local user. With sign-in every decision records the signed-in user (
decidedBy: sub, name, email). An approve rule cannot yet require a role ("a partner approves" is a pause for any signed-in person, member or admin).
Two browser guards hold in every mode, because a page the lawyer visits can reach a loopback port.
Every POST (documents, tasks, cancel, gate decisions, Manage, logout) from another site is refused 403
cross_origin (Origin other than the request's own host, or Sec-Fetch-Site other than
same-origin/none; text/plain and multipart/form-data need no CORS preflight), so no site
can spend the budget or decide a human gate (TestWritesRefuseCrossOrigin); under sign-in the same
check runs on every unsafe method (DELETE too) before the session is read, so the session cookie
never carries a cross-site write (TestSignInGuardsTheAPI). Every request but
GET /health addressed to a DNS name other than localhost (and, under sign-in, BIGLAW_PUBLIC_URL's
host) is refused 403 bad_host (DNS rebinding would otherwise make another site BigLaw's own
origin): address BigLaw by IP, localhost or its public name (TestRefusesRebindingHosts). The UI
cannot be framed (X-Frame-Options: DENY, frame-ancestors 'none': TestUIRefusesFraming).
Setting BIGLAW_OIDC_ISSUER and BIGLAW_OIDC_CLIENT_ID (and BIGLAW_OIDC_CLIENT_SECRET for a
confidential client) turns on sign-in with OpenID Connect: the authorization code flow with PKCE
(S256), against any standards-compliant issuer (a self-hosted identity server, a hosted identity
service, a corporate directory). It is built on the Go standard library alone (no OIDC or JOSE library).
- Flow.
GET /auth/login[?next=/#/…]reads the issuer's/.well-known/openid-configuration(once; itsissuermust equalBIGLAW_OIDC_ISSUERexactly, its endpoints be https, and S256 be among its PKCE methods when it lists any), seals the sign-in in flight (a randomstate, a randomnonceand PKCE verifier, where to return, and when it began) into the login cookie with AES-GCM (__Host-biglaw_loginover https, 10 minutes, the age checked inside the sealed payload too), and redirects to the issuer with scopeopenid email profile. Nothing is stored on the server until a sign-in completes, so anonymous sign-ins cost no row and no number of them can refuse anyone else's (TestUnfinishedSignInsNeverLockAnyoneOut). The sealing key is made at process start: a restart or a deploy ends the sign-ins in flight (their user clicks Sign in again), and several replicas behind one name need sticky routing (a callback must reach the process that sealed its cookie; sessions themselves are in Postgres and work on any replica).GET /auth/callbackclears the login cookie at once (single use in that browser), opens it (a cookie this process did not seal, or one tampered with, is refused), requires the callback'sstateto be the sealed one (a callback is honoured only in the browser that started it: login CSRF), and then trades the code with the verifier and the client's credentials (client_secret_basic, or_postwhen the issuer offers only that) and verifies the ID token: signature by the issuer's JWKS (RS256, RS384, RS512, ES256, ES384;none,HS*and any other alg refused before a key is looked up, a key used only for its own type and curve and its JWKSalg,octkeys never loaded, RSA keys of at least 2048 bits),iss,aud(withazp: present, it must be the client; several audiences need it),exp,iatandnbf(when present) within 60 s of skew, the sign-in'snonce, asub. Claims are decoded strictly, by their exact names: a token that repeats a claim, holds a claim named like one BigLaw reads in other case (Email,EMAIL_VERIFIED,SUB: Go's JSON decoder would otherwise let it override the real one) or one of the wrong JSON type is refused;email_verifiedcounts only as the JSON booleantrue. The JWKS is cached and fetched again for akidit lacks (key rotation), at most once a minute (a failed fetch too). Discovery and JWKS fetches are shared by every caller waiting for them (one request at a time per kind, 10 s, no lock held across it; a failed discovery is answered from memory for 5 s), so a slow or down issuer neither queues sign-ins nor is flooded.nextis a path on this server only, at most 512 bytes (longer:/). Redirects from the issuer's endpoints are not followed and answers are capped at 1 MiB. - Replay without server state. A replayed callback needs that browser's login cookie as well as
the URL, and still fails at the issuer: the code is single use and bound to the PKCE verifier,
and the ID token to the sealed nonce (
TestCallbackRefusalsreplays one). A refused sign-in is logged at most once a second, so a flood of bad callbacks cannot flood the log. - Sessions (migration
0011_sessions.sql). A sign-in creates a server-side session row; the cookie holds only its random 256-bit id (opaque,HttpOnly,SameSite=Lax,Path=/;Secureand named__Host-biglaw_sessionwhenBIGLAW_PUBLIC_URLis https,biglaw_sessionon loopback http) and the table only that id's SHA-256. A session ends after 8 hours without a request or 7 days after sign-in, whichever is first;POST /auth/logoutdeletes the row, so a copied cookie dies with it. Every sign-in issues a new id and deletes the browser's previous session (no fixation).GET /meis the session's user{id: sub, name, email, admin, authEnabled: true, model}(model: a lead model is set up). The issuer is not asked again during a session: disabling an account there ends its BigLaw sessions only at their idle or absolute end. To end them now, an admin callsPOST /manage/sessions/revoke {"user": "<sub or email>"}(every session of that sub, or of that email case-insensitively;{"revoked": n}); an open event stream (/tasks/{id}/events) checks its session every 10 polls (about 5 s) and ends withevent: signedOutonce it is gone (logout, revoke or expiry). - Every API route needs a session: without one it is 401
unauthenticated; onlyGET /health, the UI's own files (so it can show its sign-in page) and the three sign-in routes are open, by exact pattern (api.public: a new route, under/auth/or not, is behind the session unless it is added there).serveputs whatever it mounts behind sign-in when sign-in is configured. A database failure reading a session is 503, never a sign-out (TestEveryRouteNeedsASessionsends every route and spelling raw). - Roles. Admins are the accounts
BIGLAW_ADMINSnames (a verified email, or asub); they edit Manage, set secrets, import and enable custom tools and webhooks, press Test and revoke sessions. Everyone else the issuer signs in to this client is a member: they submit tasks, read everything, and decide gates (lawyer review); every Manage write is 403forbiddenfor them. An email entry matches only the address the issuer signed, as it signed it:email_verifiedthe JSON booleantrue, the address plain printable ASCII (one with a space, a control or format character such as a soft hyphen or zero-width space, or any non-ASCII character never matches, andBIGLAW_ADMINSrefuses such an entry), compared byte for byte after ASCII-only lowercasing (no Unicode folding: KELVIN SIGN is notk). An unverified claim of an admin's address is a member, and its address is not shown. Admin is decided on each request from the session's identity, so a restart with a shorter list demotes at once. Chosen over a configurable claim because it needs no issuer-side group or role mapping and works the same with every issuer. Prefersubentries where the issuer lets users, or an upstream provider it brokers, set an email it then marks verified: asubis the issuer's own identifier for the account, an email only as trustworthy as the issuer's verification of it. - Turned on with it: Manage is writable by admins, and secrets, custom MCP/HTTP tools and
webhooks work for them under Compose and in containers (
RemotePolicyis on; the admin guard keeps members out). Change-log entries, secrets' "set by", an accepted tool'sacceptedBy, Test calls and gate decisions record the user (Name <email>, orName (sub)), never "Local user", and every task records who submitted it (submittedBy, migration0012_task_submitter.sql; the Task screen shows the name, with the email on hover to admins). A member never sees another person's email: tasks'submittedByand gates'decidedBy, the change log's and history's authors and secrets' setters are names only in every response a member reads, and an accepted tool's file (acceptedBy, shown in Manage and the export) and a Test call's task record the name alone (TestMembersNeverSeeAnEmail); admins see the emails. A display name is never an email: the issuer'sname, elsepreferred_username, unless either holds an@, else the email's local part, else "Admin" or "Member" (@,﹫and%40count as@); a stored email-shaped name is shown to members as its local part, and members get noid(sub) insubmittedByordecidedBy, since some issuers use the email as the subject. Display names are the issuer'snameclaim, which a user may be able to edit there: the stored sub and email are what identify them. - Who may sign in is the issuer's decision: BigLaw admits every account the issuer authenticates for this client id as a member. Use an issuer (a realm, an application) whose sign-in is limited to your firm; a consumer or multi-tenant issuer would let anyone in.
- Never logged or returned: tokens, codes, PKCE verifiers, state, cookies and the client secret
(
TestSignInNeverLogsSecrets,TestServeWithSignIn); an issuer's error is shown only as its OAuth error code. Sign-ins are logged with sub, email and whether they are an admin.
Worked example (Compose, a generic issuer at https://idp.example.com/realms/biglaw, BigLaw at
https://biglaw.example.com):
- At the issuer, create a confidential OpenID Connect client
biglawwith the standard (code) flow, PKCE S256 if it can require it, and the redirect URIhttps://biglaw.example.com/auth/callback; note its secret. Limit who may sign in to it. - In
.env:BIGLAW_PUBLIC_URL=https://biglaw.example.com,BIGLAW_OIDC_ISSUER=https://idp.example.com/realms/biglaw,BIGLAW_OIDC_CLIENT_ID=biglaw,BIGLAW_OIDC_CLIENT_SECRET=…,BIGLAW_ADMINS=ada@example.com. - Run a TLS reverse proxy on the host for
biglaw.example.comthat forwards to127.0.0.1:3101and keeps theHostheader (BigLaw comparesOriginwith it, and answers only that name). docker compose up -d; serve logssign-in ononce it has read the issuer's discovery document. Openhttps://biglaw.example.com: the UI shows a sign-in page, the header shows the user and Sign out.
Locally, an issuer on loopback (BIGLAW_OIDC_ISSUER=http://127.0.0.1:8080/realms/dev) and the
default BIGLAW_PUBLIC_URL work over plain http, with cookies that are not Secure and have no
__Host- prefix. Browsers do not separate cookies by port, so every other service on
localhost:* / 127.0.0.1:* receives BigLaw's loopback session cookie and can set its login
cookie: use loopback sign-in for development only, never with other untrusted local services, and
https for anything real.
For developers, from a checkout (to just use BigLaw, see § Install):
test -e .env || sed "s/^POSTGRES_PASSWORD=\$/POSTGRES_PASSWORD=$(openssl rand -hex 24)/" .env.example > .env
docker compose up -d --build # Postgres 16 with pgvector + biglaw built from this checkout; host port 127.0.0.1:3101 only
curl -s http://127.0.0.1:3101/healthCompose gives biglaw the database password as PGPASSWORD rather than inside
BIGLAW_DATABASE_URL, so it needs no percent-encoding. The first line above writes a random hex
password into .env (Compose does not run $(…) written inside .env), and only when there is no
.env yet: an existing one keeps its settings and the password its pgdata volume was created with.
Compose's own .env parsing does constrain it, though: unquoted, a value is cut at # and $ is expanded (a$b fails, and
abc #def becomes abc, on both the Postgres and the biglaw side). Use a hex password, or
single-quote your own (POSTGRES_PASSWORD='…') without a ' in it.
Without Docker (Go 1.26+, any supported Postgres ≥ 14 with the pgvector extension installed,
e.g. the postgresql-16-pgvector package, or pgvector built from source; § Database):
createdb biglaw
make build # static binary: CGO_ENABLED=0, version stamped (embeds ui/dist if built: make ui build)
BIGLAW_DATABASE_URL='postgres:///biglaw?sslmode=disable' ./biglaw serve
# hybrid search: an embedding model on any OpenAI-compatible endpoint, e.g. Ollama's
BIGLAW_MODEL_URL=http://localhost:11434/v1 BIGLAW_MODELS=embed=nomic-embed-text \
BIGLAW_DATABASE_URL='postgres:///biglaw?sslmode=disable' ./biglaw servepostgres:///biglaw uses the libpq defaults (a local socket or PGHOST, your OS user or
PGUSER). The server opens the database and runs migrations before it starts listening, so a
connection to the port is answered as soon as it is accepted.
- pgvector. Migration 0003 adds a
vectorcolumn to the chunks, so the database needs the pgvector extension.store.OpenrunsCREATE EXTENSION IF NOT EXISTS vectorbefore migrating (under an advisory lock: concurrent starts would collide). Extensions are database-wide, so this is outside the numbered per-schema migrations. Creating it needs a superuser (pgvector is not a trusted extension); a role that may not, in a database without it, gets a startup error naming the fix: "the pgvector extension (vector) is missing and could not be created: use a Postgres with pgvector (the pgvector/pgvector images) or have a superuser run CREATE EXTENSION vector in this database". An extension that already exists needs no privilege (TestOpenNeedsVector). Compose'spgvector/pgvectorimage and CI's carry it; whether Render's managed Postgres offersvectoris not verified here (render.yamlis inert until sign-in is set). Thevectortype must be on the connection'ssearch_path(it is when the extension sits inpublic, the default). - Migrations run on every start. A process that finds another holding the migration lock logs "waiting for the migration lock" and waits until that one finishes or it is stopped (a signal then gives a clear "stopped … waiting for the migration lock" error). Connecting is bounded at 30 s; waiting for the lock is not, so a long migration in one replica does not crash-loop the others.
- Each migration file runs in one transaction together with its
schema_migrationsrow. A file may notCOMMIT/ROLLBACKitself (the runner detects it and refuses), and therefore cannot use statements that refuse to run in a transaction, such asCREATE INDEX CONCURRENTLY. - Migrations are forward-only. The server refuses to start if the database records a migration this binary does not have, or one whose file changed after it was applied. Rolling back the image (an older tag, Render's rollback button) after a release that added a migration therefore fails at start with "database has migration … which this binary does not know". To go back, restore the backup taken before the upgrade, or deploy a forward fix.
- Pre-release: until v2's first release,
0001_init.sqlmay still change. A database created by an earlier pre-release build then refuses to start ("migration 0001 was changed after it was applied"); recreate it (docker compose down -v, ordropdb/createdb). From the first release on, applied migrations are never edited. - Back up with
pg_dumpbefore every upgrade (all state, files included, is in Postgres), for exampledocker compose exec postgres pg_dump -U biglaw -Fc biglaw > biglaw.dump; restore withpg_restore.
Scope (G1). Every read takes a scope, the task's document ids: Search, Outline, Section,
VerifyQuote, Get, File and Resolve treat a document outside it exactly as one that does not
exist, and a file is reachable only through a document in scope (TestRetrieveNeverLeavesMatter,
TestFileNotReachableOutsideMatter). Ids compare case-insensitively, as Postgres compares uuids.
Ingest. The type is detected from the content, never from the name or the declared type:
%PDF- is a PDF, a ZIP with word/document.xml is a .docx, valid UTF-8 without NUL is text.
a PNG, JPEG, GIF or WebP image is transcribed (§ Vision transcription; a TIFF is 422
scan_encoding_unsupported). Anything else is refused with 415 unsupported_type;
a damaged, encrypted or over-2,000-page PDF and a damaged .docx are 422 unreadable. A refused
upload leaves no row behind (TestIngestRefusalLeavesNothing). A document that has nothing
readable (a PDF with neither text nor JPEG scans, a .docx holding only images, an empty file) is stored with
noText: true and a note saying so, never as a silently empty document
(TestScannedPDFFlaggedNoText); a PDF with some blank pages keeps its text and its note counts
every page that was not read (listing the first ten). PDF pages are joined with a form feed.
PDFs and .docx files are parsed in a bounded child process of the same binary (no environment,
so it never holds the server's secrets; killed when its request ends, after 2 minutes, or with its
parent; on Linux a hard 1 GiB data cap), so a hostile file cannot take the server down
(TestHostilePDFContained, TestChildBoundsItself). A document's text is capped at 16 MiB
(maxText; the file at 64 MiB): more is 422 unreadable. Two extractions run at once; an upload
waits at most 10 minutes for a slot, then is 503 busy. The child's bounds and the .docx reader's
rules: docs/documents.md § Ingest.
All extracted text, uploaded text included, has invalid UTF-8 replaced and control characters other than tab, newline, CR and form feed turned into spaces, so it can be stored.
Section tree, chunks and search. A document is parsed into a byte-exact section tree and cut
into search chunks of at most 400 tokens (a table's rows grouped). Search is Postgres full text,
ranked deterministically and scoped to the caller's documents; with an embed role it is hybrid,
fused with an exact cosine ranking of the scope's embedded chunks (no approximate index, which
breaks scoped recall). The bounds, the rules and the cost measurements:
docs/documents.md. Gate E4 (TestHybridRecallProofRuns) is not yet
judged: the committed tape is a hash embedder's offline self-test, on which the gate skips; lexical
search alone measured 0.882 (docs/documents.md § Gate E4).
Vision transcription (PR 3c). Images and PDF pages with no text layer, or only a stamp, are
transcribed by the vision role only, each page read twice by two prompts: agreement under 0.75
refuses the upload (422 transcription_unreliable), under 0.9 marks the page low confidence;
[illegible] is never filled; a mixed PDF keeps its text layer. A citation into a transcript is
marked @transcript and capped at 0.85. With no vision role an image is stored waiting (503
vision_not_configured, the original kept). The reading rules, bounds and slots:
docs/documents.md § Vision transcription.
- Transcription jobs (
jobs.go). With a vision role set,servetranscribes waiting documents at startup and every 15 minutes, oldest first, one at a time, each under a 40-minute lease in the database (two servers never take the same one; one whose server died mid-job is taken again when its lease ends), completing it under its own id with its original file. One its reading refuses (unreliable, no content, unsupported, too many pages, damaged, rejected by the model) becomesstatus: failedwith the reason as its note. Any other failure ends that run and releases the lease, and the document waits for the next run with a note saying why: a stop (SIGTERM), a wrong model setting (401/403/404model_not_configured), a rate limit or busy reader slots spend none of its attempts (TestJobConfigErrorSpendsNoAttempt); an outage (or a database failure) spends one, and the third fails it; a document whose server died during three attempts (an OOM kill, say) is failed at its fourth claim without a call, not retried forever (TestTranscriptionJobResumesAfterRestart). The run logs how many it transcribed and failed. The operator re-queues failed documents (after fixing the model setting, say) withUPDATE documents SET status = 'needs_transcription', attempts = 0, lease_until = NULL, notes = ARRAY['Waiting for transcription (re-queued by the operator). The original is kept.'] WHERE status = 'failed'(inpsql; tested verbatim). The contract v1 fields (POST /documentswithcontent+contentType→ 202transcribing,GET /healthcapabilities) are PR 8's (PLAN PR 8), not built here.
Page reader. Outline lists every section in order as {sectionId, number, title, level, tokens}, where tokens estimates what Section returns for it: the section with its
subsections. Section reads that text verbatim from a character offset, at most limit tokens
(default 2,000, at most 8,000), cut at white space; a longer section comes back with
truncated: true and next, never silently cut, and the pages join to the section exactly
(TestOutlineHasNumbersTitlesTokens, TestSectionPaginates). A table's page (a sheet, a .docx
table: two or more tab-delimited rows) is whole rows, at most TablePageRows (25), and a page after
the table's first names its header row in header (with headerAt, where it starts): a reference to
the row, read where the page's own table starts (a table starts after the section's start, a blank
line, prose or a # marker; looked for in a window before the page that doubles from 64 KiB until
the table's start is in it, bounded by the section: TestTableHeaderIsThePagesOwn,
TestTableHeaderOfASecondTable), never copied into the page's text, which stays verbatim (TestTablePagedByRows). An offset past 2^31 − 1 is 400 and a
section id past it is 404, never a database error.
Verification ladder (v1's tabcite ladder): exact substring, confidence 1.0; tolerant
substring (curly quotes straightened, U+2010/U+2011 hyphens read as -, white space collapsed, case folded on both sides; TestToleranceFoldsHyphens), 0.95;
a quote with | between table cells where the document separates them with tabs (an .xlsx row) is
matched with its separators set aside, still tolerant but at 0.9 (CellConfidence,
TestTableRowQuotedWithPipesVerifies); one
paraphrase-judge call over the best-matching window of the document (at most about 3,000 bytes
around the span holding most of the quote's words), capped at 0.8; when the judge is less than
0.75 sure, three independent votes, a strict majority needed, confidence 0.75 × votes/3, below
the judge's cap; otherwise none with a note (TestLadderMethodsAndCaps and the carried
TestCitation* vectors). The judge is a function the caller supplies (the model wiring lands with
the agent runtime, PR 4a). A judge failure is returned as an error, never as "unverified",
whether it is the first call or any one of the three votes, since a lost vote could have decided
the majority (changed from v1, G6: TestCitationJudgeFailureIsAnError). VerifyQuote also names the deepest
section holding the match. Resolve maps a model's citation by file name (any case, directory or
extension) to the one document in scope with that name; an ambiguous name resolves to nothing.
Upload and download. POST /documents/upload[?matter=N] takes multipart/form-data with one part named
file, streams it into the files table, ingests it and files it under matter N (also a scan left waiting for vision; N is refused 400 before anything is read when over 64 bytes or holding what a file name may not, as POST /documents' matterNumber is): 201 with the document (id, name,
contentType (detected), fileId, method text|text_layer|vision, noText, status
(ready|needs_transcription|failed), transcript (when anything was transcribed), pages, notes,
sections, chunks, createdAt). A part with no file name is 400 bad_request; the declared
type is kept as the file's metadata only (a wildcard such as */* is stored as
application/octet-stream). Errors are {error, errorType}: 400 bad_request/bad_name/
bad_content_type, 403 cross_origin, 408 upload_timeout, 413 too_large/too_many_pages, 415, 422
unreadable/transcription_unreliable/no_content/scan_encoding_unsupported, 499
cancelled, 500 internal (logged, fixed text), and a vision call's failure as its model kind (502
model_unavailable, 503 model_rate_limited/model_not_configured, 504 model_timeout; fixed text). 503
vision_not_configured also carries the stored document. A client must send at least 64 KiB every 30
seconds and the whole file within 15 minutes, or its read fails and its upload slot and pool
connection are released at once (TestUploadReadDeadline: 16 stalled clients and one trickling
client, then the slots are free, the pool is back to its baseline, a 17th upload succeeds and no
file row persists; TestUploadTotalDeadline). A browser request from another site is refused
(Origin other than the request's own host, or Sec-Fetch-Site other than same-origin/none),
because multipart/form-data needs no CORS preflight. GET /documents/{id}/file returns the
original with the detected content type (never the uploader's claim), nosniff,
Content-Security-Policy: sandbox, Content-Length and an RFC 6266 attachment header: filename*
carries the name (UTF-8, percent-encoded), and both it and the ASCII filename= fallback (non-ASCII
and % become _) are safe to save on Windows (<>:"/\|?* and controls become _, a device name
such as CON, aux.txt or COM1.tar.gz gets a _ prefix, trailing dots and spaces go:
TestDownloadNameSafe). The download streams: the file's size and SHA-256 are verified in a
first pass (so corrupt bytes are never sent), then it is sent one 1 MiB chunk at a time under a
read slot, each 64 KiB under its own 30-second write deadline and the whole within 15 minutes, so
a client that stops reading is cut within a window and holds at most one chunk meanwhile
(TestDownloadBounded: once all 4 read slots' holders are blocked writing to their stalled
clients, 12 stalled downloads of an 8 MiB file hold +8 MiB of live heap, 2 chunks per slot, under
a bound of 2 chunks per slot + 8 MiB, and were all cut after about 4.9 s at a 1.5 s window; the route used to hold a whole file per stalled client;
TestDownloadDeadlinePerWindow pins the 64 KiB per deadline). The last chunk is sent only after
the streamed bytes' hash matches, so a file whose rows change between the verifying pass and the
streaming pass reaches the client as a short body, never as a complete 200
(TestReadFileWithholdsUnverifiedTail). Where
a deadline cannot be set (a response writer that hides its connection, such as a middleware
wrapper without Unwrap), an upload is refused and a download cut before its first byte, never
run unbounded (TestTransferDeadlinesFailClosed). Delete
removes a document with its sections, chunks and original file in one statement; deleting either a
document or its file in any other way (SQL, a later cascade) takes the other along: a trigger and a
cascade (TestFileDeletedWithDocument). A file left without a document by a server that died
mid-ingest is deleted at the next serve start once it is an hour old (TestOrphanFilesSwept);
no live upload is that old (15 minutes to upload + 10 to wait for a slot + 2 to read + 10 to wait for a reader + 10 for the vision calls). A stop
(SIGTERM) waits 10 s for requests in flight, then cancels them: an ingest still running answers
503 stopping and removes its file, serve exits 0 with a warning, and connections still open
after another 10 s are closed (TestServeStopCancelsIngest).
The memo workflow (§ Memo workflow) drives these; everything here is tested with model.Fake or no
model. Every tool is registered once with a strict-shaped typed spec (at most 48 registered,
agent.MaxTools, and 24 visible to one agent, agent.MaxVisible; specs are data in each package's
specs/), and every call goes through Runtime.Invoke in the one loop (Runtime.Run, the lead and
its subagents). Tool outputs are bounded by type and never trimmed (one page of agent.PageBytes,
12 KB, with next or truncated; a result over 100 KB is the typed refusal result_too_large); a
model call holds its worst-case cost from the task's budget; the tool bandit only hints. The memo
tools are retrieve, verify_quote, numbers, join_discrepancies, coverage and BELO-lite. In
full, with the bounds, the paging rule and this layer's limitations:
docs/reference.md § Agent runtime; the join:
docs/figures.md.
POST /tasks with workflowType: "memo" (the only workflow built; diligence and
contract_review are 400 until PRs 5 and 6) stores a task and wakes the runner. The lead agent
(role lead, prompt internal/engine/specs/lead.md) sees 12 tools in a fixed order: retrieve,
ledger, sweep, extract_facts, analyze_issue, check_deviation, numbers,
join_discrepancies, draft_section, committee, finish, use_skill (§ Manage, Skills). A task runs on its snapshot of these specs (§ Manage). Specs are data
(internal/engine/specs/*.json, subagents specs/agents/*.{json,md}: the five above plus the
critics prosecute, reproduce, audit_gaps). Everything below is tested with model.Fake.
How a run works, in order (each pass's full rules, with the tests that pin them: docs/reference.md § Memo workflow; the figure rules: docs/figures.md):
- The passes: the ledger (one table, a JSON row per kind and key; a subagent may only read it and
never sees a quarantined finding, G3); evidence (
extract_facts,analyze_issue,check_deviation, on thespecialistrole, every answer checked by Go before it reaches the ledger: a finding is verified only when every quote is, G2, else quarantined and never drafted from, G3);sweep(every page once, most relevant first); drafting (draft_section, one issue a call);committee(three context-free critics, at mostmaxCycles, 3); policy (P1, P4); andfinish(lint G5/G8, coverage, P6/P7, then the render: Markdown with Limitations, the Computed figures block, the Evidence Note and Sources, and the gates). - Gates (G7): every deliverable opens a gate (
G-deliverable-N); a cited finding gets its own (G-<fid>) when it rests only on low-confidence transcript pages, when it was admitted at low confidence (Finding.Low: an unclear figure reading, a deviation its section check could not confirm, a limited memo figure or ⚠ worksheet input, afinding_admittedapprove rule), or when an open HIGHprosecutefinding says it is unsupported (finish.gates,gated). The run stopsawaiting_gate; approving the deliverable completes the task; rejecting it (a reason is required) puts the reason in the lead's log as a note step and the run resumes. Once all finding gates are decided the run resumes with the decisions; a rejected finding leaves the memo. - Grounding collapse (G4): from 8 findings on, if more than
BIGLAW_COLLAPSE_THRESHOLDof them are quarantined the task fails (strict, default) with a grounding alert, or (warn) carries the alert into the Evidence Note. - Model failures (G6) end the run
failedwith the kind's fixed text (model_rate_limited, …), never a finding; of the endpoint's words only an error answer's type (or code) and message, the whole of it redacted (the key; a key prefix and its fragment; any run of 32 or more key or base64 characters; a masked key's tail; a bearer, basic,key=orAuthorization:value; a URL; an IPv4 address; a host name ending in a top-level-domain shape, never a dotted path such asmessages.0.content) and then cut to 240 bytes ("the model endpoint failed: HTTP 400 (invalid_request_error: Your credit balance is too low …)", bench7;TestProviderErrorTypeAndMessage,TestProviderErrorRedactsTypeCodeTailsAndHosts,TestRedactKeepsPathsHidesCredentials).
Durable runs. Each lead turn and tool call is a journaled step in task_steps, committed in one
transaction with the ledger rows and bandit statistics it wrote. A process claims a task with a lease
(30 s, renewed every 10 s) and runs at most 4 at once; on resume the committed steps are replayed (no
model call repeated) and a step in flight is charged (lost, shown in the cost ledger) and issued
again. A run stops finished (gate open), budget_exhausted or max_steps (then finish is forced
from the reserve, open findings disclosed; maxSteps defaults to twice the call budget, at least
400), awaiting_gate, cancelled or failed. In full:
docs/reference.md § Durable runs.
Packs: jurisdiction and practice guidance (internal/engine/packs/{jurisdiction,practice}/*.md, embedded; an admin may override one, § Manage): us, us-ny,
litigation, corporate-ma, front matter plus a checklist, all candidate (no named lawyer has
reviewed them, which every deliverable's Limitations says). A task's jurisdiction selects packs by
prefix (US-NY → us, us-ny). The full catalogue is PR 12's.
REST API (stdlib net/http; JSON; lists never null; errors {error, errorType}; shapes in
DESIGN § UI contract):
GET /health
POST /documents {name, text, matterNumber?} → Document (text only; files: /documents/upload)
GET /documents[?matter=N] GET /documents/{id} DELETE /documents/{id}
GET /documents/{id}/outline GET /documents/{id}/sections/{sectionId}?offset=&limit=
GET /documents/search?q=&ids=a,b POST /documents/upload[?matter=N] GET /documents/{id}/file
GET /clients matters derived from documents' matter numbers (clients: PR 8)
POST /tasks {description, workflowType, documentIds[], jurisdiction?, matterNumber?, maxSteps?, toolBandit?: on|off} → 201 Task
GET /tasks GET /tasks/{id} Task with run {status, step, stopReason, budget, openFindings}, gates, findings, output
GET /tasks/{id}/steps?after=N the step log, paged
GET /tasks/{id}/events SSE: step (each once, in order), task (run changed), done
GET /tasks/{id}/cost per-step usage and USD (null when unpriced), lost grants, estimated wattHours when recorded
GET /tasks/{id}/deliverable.md the rendered memo
POST /tasks/{id}/cancel
POST /tasks/{id}/gates/{gateId}/approve POST /tasks/{id}/gates/{gateId}/reject {"reason": "…"}
GET /me {id, name, email, admin, authEnabled}: the signed-in user, or without sign-in the local user
GET /auth/login?next= GET /auth/callback POST /auth/logout sign-in (§ Sign-in; only with BIGLAW_OIDC_ISSUER)
POST /manage/sessions/revoke {user} (admin, sign-in only) end every session of a sub or an email → {revoked}
GET /manage/items the catalogue (§ Manage) GET /manage/items/{id}: with its files now and built in
GET /manage/items/{id}/history its versions, each with its files GET /manage/items/{id}/diff?from=&to= (a number or builtin)
POST /manage/items/{id}/versions {base, files, note} → 201 (admin; 422 invalid with problems[], 409 stale base)
POST /manage/items/{id}/revert {to, base, note} (admin; to 0: the built-in) POST /manage/items/{id}/delete {base, note} (admin; skills)
GET /manage/changes?limit= the change log GET /manage/export?format=patch|zip&item=a,b (the overrides at their repo paths)
GET /manage/secrets names, the origin each is sent to, who set them, when, used by (never a value)
POST /manage/secrets {name, value, origin} (admin; 403 without a real admin) POST /manage/secrets/{name}/delete (admin)
POST /manage/items/{server}/discover (admin) an MCP server's tools POST /manage/items/{server}/import {tools, offerToLead} (admin)
POST /manage/items/{id}/test {documentIds, input} (admin): one call of a subagent or tool, metered
GET / the web UI (embedded by `make ui build`), or a notice in a build without it
Model failures map to model_not_configured (503), model_rate_limited (503), model_timeout
(504), no_content (422), model_unavailable (502), a cancelled request to 499; a grounding
collapse is 422 grounding_collapse; an unknown task 404, a gate that is not open 409; a
cross-site write 403 cross_origin, a request by DNS name 403 bad_host (§ Exposure); under sign-in, no
session 401 unauthenticated (§ Sign-in).
Run it against a model (owner; no key exists in the build environment):
BIGLAW_DATABASE_URL=… BIGLAW_MODEL_URL=https://…/v1 BIGLAW_MODEL_KEY=… BIGLAW_MODELS='lead=<C>' \
./biglaw serve # loopback :3101; make ui build first to embed the UI
python3 eval/run.py drive --api http://127.0.0.1:3101 --model-dir v2-<C> --matter litigation --matter ma-diligence
python3 eval/lab/run.py --labs-dir ~/harvey-labs --api http://127.0.0.1:3101 --model-dir v2-<C> \
--task corporate-ma/review-data-room-red-flag-review [--tool-bandit on|off]eval/ (Python 3, stdlib only): run.py (list, validate, selftest, score,
drive), proofrun/ (driver, scorer, mock), lab/ (the Harvey LAB driver over this API),
tests/. make eval runs E0 and E3 (fixtures, scorer tests, scorer self-test; no backend). In
go test ./eval, with no model: TestProofRunsOracle (E1: an oracle model.Fake per matter through
the real engine and API, scored by the Python scorer: 1.0, verified rate 1.0; a figure its drafter
can neither cite nor compute is delivered as an unresolved check, pinned per matter as a ratchet,
unresolvedG8 and findingGates: docs/patterns.md § Ratchet pins), TestProofRunsFabricator (E2:
every matter fails with a grounding alert) and TestLabRunnerSmoke (the LAB driver against an
httptest server).
Manage: agents, tools, packs, skills and hooks (internal/engine specset/manage/skills/hookrules, internal/api/manage.go)
Everything a run uses is a file built into the binary (go:embed), and an admin can see and change
each one in Manage (#/manage) or the routes above, with no rebuild:
- Agents: the lead's prompt (
specs/lead.md), the meta and section-check prompts, the subagents (specs/agents/<name>.json+.md: description,maxTurns, budgetclass, modelrole,allowedtools,in/outschemas, prompt) and the engine's passes (sweep,committee,cover,finish,ledgerspecs). Tools: the typed tool specs ofinternal/analysis/specs,internal/docs/specsandinternal/engine/specs/{exact_calc,figure_context,use_skill}.json; their code stays Go. Packs: jurisdiction and practice guidance (§ Memo workflow). Skills: below. Hooks: configurable hooks (below). The Go around some tools and subagents (hooked,sheets,aliasJoininregister.go,finish's lint) is not an item: its checks, in plain words from the tool'sgoContractrow, are listed on that tool's own page, view only. Each item shows its contents, built-in or override (its version), what it calls and who calls it (agents' allowed lists, the lead's list, and the Go callers), and its recent usage: lead steps, model calls and USD over the last 20 tasks (task_steps; a fan-out's own calls count under it). - Versions, snapshot and validation (
spec_versions, migration 0008): every save, revert and skill deletion is a new version of the item (author, time, note), so the table is the history and the change log; a save names itsbase(stale: 409).Submitstores the overrides in effect intasks.specs, so a save reaches the next task only. Every save and revert is validated strictly, all problems at once (422 withproblems[]by file), and checked for compatibility with what Go reads and writes (compatSpec); any change to a pack's or skill's content resets it tocandidateunless the save names a new reviewer. The full rules: docs/reference.md § Manage. - Who.
api.Principalis the seam. With sign-in (§ Sign-in) it is the session's user (api.SessionUser, put on the request byapi.RequireSignIn): an admin whenBIGLAW_ADMINSnames them, a member otherwise, and every author field records them (Principal.Label:Name <email>). Without sign-in every request is the local user (api.LocalUser, recorded as "Local user"). It is an admin on a server bound to loopback for local work (no--allow-no-auth); under--allow-no-authManage is read-only (everyone may view it), unless the operator also passesserve --admin-without-auth, which makes anyone who can reach the server an admin: serve logs a warning and the Manage screen shows a banner saying so (owner decision, review M3; § Exposure). Every write wearsdocs.Guard(cross-site 403) and the admin guard (403forbiddenfor a non-admin, telling a member they are one:TestManageAdminGuarddrives it through the seam,TestSignedInManageRoleswith real sessions over every write route); reads are open to anyone who may use BigLaw (under sign-in: anyone signed in). - Export (
GET /manage/export): the overridden items (all, or?item=) as one git-style patch against the repository's paths (git applyorpatch -p1at the root; new and deleted files as/dev/null;TestExportPatchAppliesapplies it), or a zip of the files at their repo paths (withDELETED.txtnaming a deleted skill's files). The server holds no GitHub credentials: the owner opens the pull request from the export, which then makesui/src/recorded/manage.jsonstale (re-record withmake demo-record;TestManageRecordingneeds no database).
Custom agents and tools (custom.go, remote.go; migration 0009). An admin creates, edits,
tests, disables and deletes them in Manage; like every item they are versions and in each task's
snapshot.
- Subagents (
specs/agents/<name>.json+.md, the built-ins' format): name, description, prompt, class,maxTurns, role (the model it runs on), allowed tools, in/out schemas, all validated as the built-ins are. The lead is offered every subagent Go does not run itself (leadVisible); it runs throughRuntime.Invokewith the same typed-schema enforcement, metering, journal and resume. Subagents never call subagents (the runtime's rule), so "an agent's allowed list" can name custom tools, not custom subagents. A custom subagent's list names no lead-only tool,ledgerincluded (only the built-ins keep its reads);use_skillit may name (decided: a skill is read-only guidance an admin wrote, recorded as used, and the same for any agent the admin gives it to). The nameslead,meta,manage_testand every pass's are reserved. - MCP tools (
specs/servers/<name>.json: the server's Streamable HTTP URL and a secret by name;specs/tools/<name>.jsonkindmcp): Import tools connects (initialize with a session id,notifications/initialized,tools/listwith its cursor; an SSE or JSON answer), converts each input schema to BigLaw's strict subset (convertSchema: optional fields nullable and sent only when not null;anyOf/$ref/open objects refused with the reason) and saves each as a version. The server must speak protocol 2025-06-18 or 2025-03-26; every session is ended (HTTP DELETE). A call is one handshake plustools/call, within one 30 s deadline for all of it (Discover/Import too). - Imported descriptions and schemas are untrusted. The converted input schema is third-party text
too: each property description is cleaned and capped at 200 characters, an enum value or property
name that is long or holds control or format characters is refused, and the schema is capped at
16 KiB; a re-import that changes it disables the tool until an admin accepts it again, with the diff.
The server's text for a tool is cleaned (control and format
characters and line breaks become spaces, so it can add no line of its own) and capped at 2 KB, kept
in the file's
imported.text, and shown to the lead only quoted inside BigLaw's own sentences as third-party text. An imported tool is disabled until an admin reads and accepts that text (Edit: Accept and enable; the save records the saving admin asacceptedBy, whatever the file says), and is disabled again whenever a re-import (or a hand edit) changes it; Import shows the change as a diff. A tool whose name, description or schema holds the server's secret is not importable. - HTTP tools (kind
http): a typed input to an https URL, as a JSON body (POST) or query parameters (GET), with a secret in one header. - Rules for both: https only, on port 443 or 8443; no user info in a URL; a host that is never
public (localhost,
*.local,*.localdomain,*.internal, a numeric spelling such as2130706433, and any address the IANA special-purpose registries mark not globally reachable: private, loopback, link-local, CGNAT, metadata, documentation, benchmarking,::/96,::ffff:0:0:0/96, NAT6464:ff9b::/96and64:ff9b:1::/48, 6to4 over a denied IPv4, Teredo and the rest of2001::/23, site-localfec0::/10) is refused when saved, and every connection is checked when it is dialled (dialCheck, so a name that resolves to such an address, DNS rebinding included, is refused too); one refusal text whatever the reason (no port or host oracle); redirects only to the same host, at most 3; no proxy:HTTPS_PROXYis ignored by design (a proxy would connect past the check), so custom tools need direct egress; 30 s for a whole call; a 1 MB answer cap (over it: refused) and 64 KB of headers; per-toolenabled(a disabled tool is not offered and a call fails closed) andofferToLead. The output is{source, untrusted: true, text, truncated, isError}, one page (a remote call is never repeated to page it). Each call is a journaled step (a crash after it commits replays it: the remote is not called again) and a log line (tool, source host, status, bytes, ms; never a secret). A running task keeps its snapshot: disabling or editing a tool reaches new tasks only; to stop a running task's calls, delete the tool's secret (read at call time) or cancel the task. - Secrets (
secretstable): set by an admin for one origin (https://host:port; migration 0010) and sent to no other: a save naming a secret for a URL of another origin is refused, a call to one is refused, so moving a tool to another origin takes setting its secret again, value and all. Listed by name, origin, setter and the items naming them; never returned by any route, logged, put in an error, the snapshot or the export. Only the bound origin ever receives the key. What that origin sends back is redacted of an exact echo of it before it reaches the API,task_steps, the logs, the UI or a model: the key with and without its prefix, base64 in either alphabet (padded or not), URL- and JSON-escaped, and a Basic pair and its password; so is every error built from remote data (secretRef.scrub: a schema's property path, a call's failure), and the server's own protocol version is never echoed. The check runs on what the server sent, whole, before anything is cleaned or cut to its cap (a server name, a tool's or a property's description, a problem), so a key that straddles a cap is caught too: a listed tool holding it is not importable. An origin that obfuscates its own key (splits, spaces or hex-encodes it) is not stopped: it already holds the key. They are stored in Postgres as everything is (back up and protect the database accordingly); a task resolves a secret by name at call time, so a secret changed mid-run reaches the run's later calls. - A real admin only: without sign-in, serving with
--allow-no-author--admin-without-authturns secrets and custom outbound calls off (RemotePolicy.Off): setting a secret, Discover, Import and a custom tool's Test are 403, custom tools are left out of the lead's list (a Limitations line says so) and a custom tool's call in a run (a subagent's) fails closed. So without sign-in, custom tools and secrets work only for a nativebiglaw serveon loopback, with neither flag. With sign-in they work for signed-in admins under Compose and in containers too (the policy is on; members are refused by the admin guard:TestSignedInRemotePolicy,TestServeWithSignIn). - Test (
TestCall, admin): one call of a subagent or tool as new tasks would make it, over a matter's documents, within 8 model calls and $0.25 (and never more than a task's budget); journaled as the one step of a cancelled task named for the test (started at its grant, every model call metered as it happens, settled to what it spent) and in the change log (manage_events), all written whatever the request does, so a client that goes away or a crash still leaves the spend counted. Passes,finishand the lead's own tools are tested only inside a task. The recorded demo has none of these writes. - Deleting a custom agent, tool or server is a tombstone version (revertable). What Go depends on (the memo lead's tools, the subagents and tools Go calls, the passes, prompts and packs) is refused with the reason; so is a deletion that would break the set (a tool an allowed list names, a server a tool uses). The registry's caps rose to 48 tools and 24 visible to one agent (from 22/14) to fit them.
Skills (internal/engine/skills/<name>/SKILL.md, embedded; created, edited and deleted in Manage
too): a named bundle of instructions with a one-line description, a Markdown body, optional reference
files (.md, .json, .csv, ≤ 16 of ≤ 64 KiB) and an optional tools list. Front matter: name,
description (≤ 200 bytes), status (candidate until a named lawyer reviews it), reviewedBy,
tools. Progressive disclosure: the lead's brief lists each skill's name, status and description only
(≤ 40 skills in ≤ 4 KiB, refused at save); use_skill {name, file, offset} returns the body or a
reference file one page at a time (agent.TakeText; next continues it), spends no model call, is a
journaled step like any tool (so a crash resumes past it) and records the skill read in the ledger
(kind skill) with the step. Callers: the lead (MemoVisible, now 12 tools; use_skill may run
before a plan, P1); an admin may name it in a subagent's allowed tools. A skill grants no tool: its
tools must be tools that use_skill's callers may already call (refused otherwise), and the answer
says to call only tools the caller was offered. A deliverable that read a candidate skill names it in
Limitations, as candidates() does for packs. Starters (all candidate): deadlines,
figure-conflicts and requirement-deviation, process guidance taken from the lead's prompt and the
numbers, join_discrepancies and check_deviation specs (no legal content of their own); deadlines
carries examples.json, the numbers calls its spec gives as examples.
Configurable hooks (internal/engine/hookrules.go; items rule.<name>, files
internal/engine/specs/hooks/<name>.json, created, edited, tested by a run and deleted in Manage like
any item, in each task's snapshot). A rule is {name, enabled, order, event, match, when, action, failure}:
Events before_call and after_call (every Runtime.Invoke but finish and verify_quote),
finding_admitted and task_finish; actions block, approve (a lawyer's gate on one call the lead
makes, single use), check (a named subagent's verdict), webhook and limitation; every outcome is a
ledger hookrun row written with its step. Matchers, each action's effect, order, the failure policy
and the checks at save: docs/reference.md § Configurable hooks.
Files are stored in file_chunks rows of at most 1 MiB (a CHECK in the schema refuses a
larger row), written in one transaction from a stream. lib/pq moves bytea as hex text, so each
chunk costs a few times its size in transient memory; chunking bounds writing by the chunk,
not the file. ReadFile streams a file to a writer one chunk at a time (one query per chunk, so
it holds two chunks: the last is written only after verification); GetFile reads it into one
buffer of the recorded size. Both check the recorded size against the 64 MiB cap before reading
content and verify the size, the chunk count and SHA-256 before the last chunk is written, so a
writer never receives a whole file that fails the check (TestReadFileWithholdsUnverifiedTail;
the download route also verifies once before sending headers, so a corrupt file is an error
status, not a short body). The SHA-256 detects storage corruption, not tampering: anyone who can write the rows
can rewrite the hash too.
An upload holds one pooled connection, inside its transaction, for as long as its reader takes.
So at most 16 uploads (MaxConcurrentUploads) run at once, leaving 4 of the 20 connections for
/health and reads. Further uploads wait for a slot until their context ends. Nothing in the
store ends a stalled upload: its slot and connection are freed when its reader returns (an error
rolls the transaction back, leaving nothing behind). Bounding a stalled client is the caller's job;
the upload route's read deadline does it (§ Documents). At most 4 reads (MaxConcurrentReads,
GetFile or ReadFile) run at once; a read over the cap waits for a slot or its context
(TestConcurrentReadsBounded, which also pins that a read holds its slot while its writer
blocks). So whole-file reads (ingest's) stay near 512 MiB, and streamed
reads (downloads) hold one chunk each, a stalled client no longer than one transfer window
(TestDownloadBounded).
Names must be 1–255 bytes of UTF-8 and not . or ... They may not contain /, \, control
characters, invisible characters (category Cf such as bidi controls, zero-width spaces, the BOM
and soft hyphens; Unicode Default_Ignorable_Code_Point such as the Hangul fillers U+3164/U+115F,
the combining grapheme joiner and variation selectors; the braille blank U+2800), line/paragraph
separators or a run of two or more white-space characters (no-break spaces included), and may not
start or end with white space, any of which can disguise an extension. ZWNJ/ZWJ are allowed once
between two letters, marks or emoji, as Persian, Indic scripts and emoji sequences need them, and
one presentation selector (U+FE0E/U+FE0F) right after an emoji symbol (❤️ notes.txt, a ZWJ
family emoji).
Names that are only unsafe on Windows (CON, aux.txt, c:evil.txt) are stored as given and
made safe on download. Content types must
be concrete media types (no * wildcard) in printable ASCII, at most 255 bytes in the canonical
form they are stored in (Text/HTML; Charset=UTF-8 → text/html; charset=UTF-8).
Measured on a 64 MiB file (before → after this layout; peak above baseline, the same for Go heap
and RSS): writing 256 → 67 MiB, reading 128 → 126 MiB at the default GOGC=100; with
GOGC=10, writing 256 → 11 MiB and reading 128 → 73 MiB. So a read holds about 64 MiB live and
peaks near 128 MiB at the default GOGC. The difference is garbage the collector has not yet
reclaimed, so a small machine should set GOMEMLIMIT (for example GOMEMLIMIT=512MiB on a
4 GB Pi) to make the runtime collect it sooner.
Memory of one ingest, end to end: measured in docs/documents.md § Memory.
Owner decision 13 (2026-10-20): BigLaw needs a live, playable UI on discover.legal before the engine
exists, run against a recorded engine, with no model calls. So the UI is built first and talks
to BigLaw only through one interface (ui/src/api/transport.ts):
http.ts— the REST API on the same origin (README contract routes; the shapes the contract left open are fixed in DESIGN § UI contract, PR 11, and typed inui/src/api/types.ts). PR 4b serves the task, step, gate, cost, client and document routes;biglaw serveserves the built UI at/(make ui buildembedsui/dist; a build without it shows a notice there).npm run devproxies the API paths toUI_API(defaulthttp://127.0.0.1:3101).recorded.ts— replays recorded runs in the browser. A build withVITE_ENGINE=recordedaliases the transport to it, so the bundle contains no HTTP code:test/offline.test.tsbuilds it and fails on anyfetch,XMLHttpRequest,EventSource,WebSocket,sendBeacon, worker, preload link or absolute URL (scripts/offline-check.mjs; the same check flags the live bundle, proving it bites). One exact string is allowed because it is displayed, never requested:https://discover.legal/(the banner's way back).
Manage (screens/Manage.tsx, § Manage): the sections Agents, Tools, Packs, Skills, Hooks and Change log; each item's contents, where it is used and its usage; for an admin an editor over structured fields (description, turn cap, class, role, allowed tools, schemas; a pack's or skill's status, reviewer, checklist or tools, and body) or the raw files, with problems shown beside their file, a preview of unsaved changes, history with a diff between any two versions or the built-in, revert, a new skill, delete, and export links. The recorded demo shows the built-in catalogue read-only (ui/src/recorded/manage.json, recorded by eval/demo/manage_test.go; no history, no export, every write refused).
Screens (hash routes, so a static bundle works under any base path): Matters (matter cards,
tasks, the new-task wizard; a "No AI model set up yet" card while GET /me's model is false), Task (run bar with status, step, stop reason, budget, Cancel;
why a failed run failed (error, groundingAlert); the deliverable gate with Approve/Reject, and a finding gate showing its finding; tabs Run log (the steps, streamed), Findings (claims,
severity, each citation with its verification badge: exact, tolerant, judge, ensemble,
… @transcript, excluded; a verified quote links to its section with the matched text
highlighted), Deliverable (the memo with [F-id] links, Limitations and Evidence Note; Download .md, Copy, Print) and Cost),
Documents (upload and file to a matter, live only; library, outline, section reader with highlight, search).
Playbooks, clients and time screens come back with the PRs that build their routes (6, 8, 9). Rejecting the deliverable asks for a reason (sent as
{"reason"} to POST /tasks/{id}/gates/{gateId}/reject, as v1's reject did) and closes the gate:
the decision is kept in decidedGates; live, the lead resumes with the reason (the task goes back to
running and the Task screen opens the event stream again, which the server ends with done at every gate (ui/src/api/follow.ts); the recorded demo has no revised run, so there it stays rejected). The Task screen's Table and
Redline tabs (diligence, contract review) are planned with PRs 5 and 6, the Documents version
timeline with PR 6. With sign-in the shell shows a sign-in page until there is a session, then the
user and Sign out in the header; members see no admin-only controls in Manage.
The recorded demo. A visitor picks one of three sample matters (Greystone v. Talbot litigation
defense, Altamira/Sorell merger control, Quillon/Fernhill license review), types a prompt or picks
a recorded task, and watches the run log replay (about 12–23 s; Skip to end). A prompt is matched
to the matter's recorded tasks deterministically (ui/src/api/match.ts: the share of its content
words a recorded task's prompt, title and keywords cover, ties to the earlier task; at least 30%
or it is off script: the UI says no recorded run answers it and offers the nearest). Search
offers four recorded searches per matter whose hits are v2's own Search results; any other
query is ranked in the browser by a port of the server's lexical formula (two legs, stemmed and
exact, idf × tf/(tf+10) per term; a plural-dropping stand-in for the English stemmer), labelled as
such on screen; it puts the server's top hit first on every recorded search (test/recorded.test.ts).
The banner is one line (Recorded run; not live …, a ← discover.legal link to the site root, and
a "How this demo works" toggle holding the provenance below); the link exists only in the recorded
bundle (test/offline.test.ts). Nothing is saved; a reload starts over.
Provenance (exact). No model has run on these matters (v1's proof-run harness says "no
real-model scores have been recorded yet"; v1's real LAB runs used Harvey's documents, which are not
in the repo; the family and employment drives' documents and outputs were never committed). So:
the documents are eval/tasks/{litigation,competition-regulatory,ip-licensing} (synthetic,
fictional), plus one scanned exhibit drawn for the demo (an affidavit of service in the Greystone
matter, consistent with its docket; eval/demo/make_scan.py draws the JPEG from
eval/demo/testdata/06-affidavit-of-service-scan.txt). eval/demo/record_test.go ingests the text
documents with docs.IngestText and the scan with docs.Ingest through v2's vision path, whose
reader is a model.Fake (named model.Fake (scripted) in the transcript provenance) returning that
same text for both readings, so the transcript is what the image shows and no model read it. It
records each document's outline (Outline), section text (Section), chunks (Parse +
Chunkify), the run-log and offered search hits (Search, lexical) and every quote's verification
(VerifyQuote, no judge) — all computed by v2 code. The plan, the claims and the memo text are the
matters' answer keys (reference answers written by hand for scoring): each step is marked
computed or scripted in the run log, and the banner and memo Limitations say so. To show the
whole ladder, a few quotes and one finding were written for the demo (demoQuotes, demoFacts)
and verified like the rest: of 79 citations across 48 findings, 74 are exact, 2 tolerant
(curly quotes typed over straight ones), 1 exact@transcript and 1 tolerant@transcript (from
the scan, capped at 0.85), and 1 is excluded: finding F5 of the deadlines task misquotes the rule's
figure ("20 days"; the excerpt says 21), fails VerifyQuote, is quarantined, left out of the memo
and named in its Evidence Note. The memo's Limitations name each of these. No judge or ensemble rung
ran (they are model calls), and no committee step is recorded. Costs are $0 because no call was made; the Cost tab quotes
v1's best Haiku LAB run ($11.52, 8.3 M tokens) for scale.
make ui # cd ui && npm ci && npm run build && npm test (CI's ui job)
make demo-bundle # ui/dist-recorded: the static demo for https://discover.legal/demo/biglaw/
# (VITE_ENGINE=recorded UI_BASE=/demo/biglaw/; then the no-network check)
make demo-record # re-record ui/src/recorded/recording.json (needs BIGLAW_TEST_DSN, Postgres + pgvector)The demo bundle is four files (index.html, one JS and one CSS asset, and the scan; about 800 KB;
the JS is 640 KB, 133 KB gzipped) and needs no server logic: copy ui/dist-recorded/ to the site's /demo/biglaw/. A
build without UI_BASE uses relative asset paths, so it also works from any directory.
go test -race ./... # unit tests; DB tests SKIP without a DSN
# a throwaway Postgres for the DB tests:
docker run -d --name biglaw-testdb -p 127.0.0.1:55432:5432 -e POSTGRES_PASSWORD=t pgvector/pgvector:0.8.6-pg16
BIGLAW_TEST_DSN='postgres://postgres:t@127.0.0.1:55432/postgres?sslmode=disable' \
BIGLAW_REQUIRE_DB=1 go test -race ./... # DB tests too; each gets its own schema, dropped after
make ci # gofmt, vet, go mod verify/tidy, static build, tests (-race, shuffled;
# then the reader child's bounds again without -race, which turns
# its memory cap off, with -v; where BIGLAW_REQUIRE_DB is set it
# fails unless TestChildBoundsItself, TestChildNearTextCap and
# TestIngestMemoryBounded each report PASS there), make eval (E0/E3),
# loc.py + its tests, docker compose config. Its race pass runs at
# -p 4 -parallel 4 (TEST_P, TEST_PARALLEL, for CPU); a test store's
# pool is storetest.Pool (4) and at most storetest.Slots (8) DB tests
# run at once across packages, so the peak stays under 50 of
# Postgres's default max_connections of 100 at any -p (PR 55 CI)
make ui build # the binary with the web UI embedded (ui/dist → internal/api/dist)
make lint vuln # staticcheck and govulncheck (network needed; CI runs both)The tests are their own record; git history and the PR notes say which PR added which.
| Budget | Ceiling | Today |
|---|---|---|
Go production lines (physical lines, non-_test.go, test-support packages included) |
reported, no limit (owner decision 17) | printed by python3 scripts/loc.py |
Packages under internal/, test-support packages excluded |
12 | 9 (agent, analysis, api, auth, docs, docs/ooxml, engine, model, store; store/storetest, engine/figtest and auth/authtest are test support) |
| Direct Go dependencies | 3 | 2 (github.com/lib/pq, github.com/ledongthuc/pdf) |
| Runtime environment variables | 20 | 18 |
| UI runtime dependencies | 2 | 2 (react, react-dom) |
UI source lines (ui/src .ts/.tsx/.css; tests, config, recording.json and manage.json not counted) |
3,200 (raised from 2,400 for Manage, owner decision) | printed by python3 scripts/loc.py |
Packages without a _test.go |
0 | 0 |
Lines in any one source file (.go, .py, .sql, .sh, .js, .ts, .css; tests included) |
2,000 | printed by python3 scripts/loc.py |
There is no total line ceiling (owner decision 17, 2026-10-23). scripts/loc.py reports the Go production total (run it for today's figure; a number written here goes stale) and fails only on the budgets that bound bloat directly: no file over 2,000 lines, ≤ 3 direct deps, ≤ 20 env vars, ≤ 12 internal packages, ≤ 3,200 UI source lines, no untested package. Each PR still reports its lines against its DESIGN budget in its notes. (The ceiling's history, 14,000 → 17,500 through owner decisions 7–16, is in PLAN.) A test-support package is one
whose directory name ends in test and that no production file outside it imports, such as
storetest. Under the coordinator's ruling it is left out of the package count, but its lines
count toward the reported Go total like any other non-_test.go file. A *test package that
production code imports is an ordinary package. loc.py also fails if LICENSE or NOTICE is
missing or a .go/.py file lacks its SPDX header. Env-var names are found statically (literal
os.Getenv/LookupEnv/getenv arguments, the config table, and BIGLAW_*/ALLOW_* literals).
An os.Getenv/os.LookupEnv argument that is not one plain string literal (a variable, a
concatenation such as "BIGLAW_" + x, a raw string) fails the check.
- Without sign-in Manage has no per-person admin: the local user is an admin on loopback, read-only under
--allow-no-auth, and anyone who can reach the server under--admin-without-auth; the change log's author is "Local user" (§ Manage, Who). Sign-in has two roles only (admin, member); every signed-in user sees every matter (per-matter access, an approve rule's role, API tokens for scripts and the clients roster are not built), and the issuer is not asked again during a session (removing an account there ends its BigLaw sessions at their idle or absolute end; an admin ends them now withPOST /manage/sessions/revoke, which has no screen yet). There is no member allowlist on BigLaw's side: who may sign in is the issuer's decision (§ Sign-in). - The engine's tests write their own skills: an export that deletes a starter skill only makes
ui/src/recorded/manage.jsonstale (re-record it). - Manage creates skills, subagents, MCP and HTTP tools and MCP servers, not packs; the compatibility check's limits are in docs/reference.md § Manage. A remote call in flight when a process dies is made again on resume (its step had not committed): remote tools should be safe to repeat. MCP tools: text content only (other parts are noted, not shown), one session per call, no server-initiated requests; the HTTP and MCP answers are one page (truncated, never paged by a second call).
- Matters are derived from documents' matter numbers until PR 8's client roster.
- Memo workflow (PR 4b):
- Every test scripts the model (
model.Fake); real models have run it only in the owner's bench and Harvey LAB runs (bench5–bench7, the Haiku LAB reruns: their logged behaviour is scripted into the tests named for them). Whether it meets gate A (v1's criteria onlitigationandma-diligence) is the owner's measurement (§ Memo workflow, run it). - The deliverable is Markdown only (
GET /tasks/{id}/deliverable.md); the.docxexport waits for PR 3d's writer. - Quote verification proves a quote is in the document, not that the claim follows from it:
prosecutechecks that, and a lawyer approves every deliverable. The G8 lint traces figures (a figure the drafter wrote by the figure reader's reading of it, to a cited span or value read clearly as the same kind, currency, scale and amount, never to one read unclearly or as another kind; a date's part or an identifier as written, digit for digit; a handle's value by construction; a figure the reader read unclearly, or left unlabelled in an answer, is flagged, never traced; one its call never read (no model, unfunded, failed, cut off or malformed: bench7) that a cited finding's own verified quotes or values state as written is listed check-first in the Computed figures block, naming those findings and why, traced only as written, and those findings gated, never a blocking lint line that strips figures from a redraft (one that only a worksheet or a handle states, or none, is still flagged:TestUnreadMemoScaledSumNeverUngated,TestUnreadMemoWorksheetOnlyIsFlagged,TestUnlabelledMemoSpanIsNoCallFailure), and the section disclosed in Limitations; a clear figure whose cited quote the reader never read (its admission's call unfunded or failed) is traced only as written, disclosed, and its finding gated for a lawyer (TestR6UnreadQuoteTracesAsWritten); one the drafter wrote at a sourced scale where the cited figure states every digit ("$5M" for "$5,000,000") is disclosed, since only the reader's scale makes it the same figure; a cited figure read at a scale never traces one written without it or from other words; a worksheet traces only when its operands are cited values, literals the cited quotes state, traced worksheets' results or counts of days (tracedSheets,TestR6LiteralWorksheetLaundersAFigure): lab-r4 r5 H1, H2, M1, r6 H1, M2, M3,TestR5G8SkipsUnreadSingleDigit,TestR5UnclearQuoteTracesUngated,TestR5NoReaderBudget), not words: a wrong party or a wrong verb with correct figures passes it. - The SSE stream polls the database every 500 ms. Cancel stops a run at once in its own process and at the next heartbeat (up to 10 s) in another; the call in flight is charged.
- A hard crash (kill -9, out of memory, power loss) during a tool call is charged the spend its
journaled model calls recorded plus the worst case of those in flight; a tool step that has made
no model call yet, and spend no model call records (a query embedding inside
retrieve, a fraction of a cent), are charged as before: the whole grant, or nothing until the step ends. What a crashed sweep read is lost with it (its findings commit with the step), so the re-issued sweep pays for those pages again; the lost spend is charged to the run, not to the sweep's share. - A forced finish (budget or max steps) delivers a draft its lint refused, marked "Delivered with
an unresolved check"; a sentence citing a finding that is not usable (rejected at its gate or
quarantined) is removed and counted in Limitations (a citation after the full stop goes with the
sentence before it), the rest stands as drafted. An abbreviation mid-sentence (
Smith v.) splits the sentence, leaving a fragment, and a table row citing one is blanked, which ends the table. - BigLaw answers only requests addressed by IP,
localhostor (with sign-in)BIGLAW_PUBLIC_URL's host (§ Exposure): any other LAN or proxy hostname gets 403bad_host. - Tool-bandit statistics are per signature across all matters; a run's practice is not yet part of its signature (empty), so memo runs in one jurisdiction with the same lead model and document-count band share one bandit row per tool.
/cost/summary(all tasks, ingest-time embeddings and vision reads) is not built; costs are per task (/tasks/{id}/cost) and per document.- The transcription jobs keep their own loop (
docs/jobs.go); moving them onto the run lease (DESIGN way 5) is deferred. - Packs are four
candidatefiles; nothing checks a pack's legal content.
- Every test scripts the model (
- The recorded demo replays answer-key claims, not a model's work; its
@transcriptbadges come from a scripted reader, not a vision model; it has nojudge/ensemblebadges (model calls); a query other than the offered searches is ranked in the browser, approximately; a rejected deliverable ends the replay (there is no revised run). - Only the memo workflow exists; diligence, contract review, the MCP server, billing and API tokens are planned.
Without sign-in the exposure rule above is the only protection: anyone who can reach the port can
upload, list and read every document, and run, approve or cancel tasks. The cross-origin check stops a web page from uploading through the lawyer's browser,
and the
bad_hostrule stops DNS rebinding; sign-in's sessions (§ Sign-in) close the rest. Scripts (eval/run.py drive) have no API tokens yet, so they need a server without sign-in. - The env-var budget is a static heuristic: code that reads the environment another way
(
syscall.Getenv, scanningos.Environ(), importingosunder another name) would evade it. Review is the backstop. - The vendor breakers key on names: an IP literal of a vendor's API is not recognised. They are
a self-imposed policy, not a security boundary. The substring match fails closed: a gateway
URL that merely contains
anthropic.comorbedrockis refused too and needs the opt-in. render.yamlhas never been deployed and is inert until its sign-in variables are set (§ Exposure). Render's internal connection string may need an explicitsslmode, and the instance plans are not pinned.- The image build and the Compose smoke test run only in CI's
dockerjob (green on GitHub since PR 2, including theCOPY LICENSE NOTICEline); the build sandbox has no Docker daemon, so they are not run locally. Nolinux/arm64image or release binaries are produced yet, so the Raspberry Pi path means building natively withmake build. - The Compose exposure check runs only where
dockeris installed (CI). An override file an operator adds after checkout is outside the repository; publishing beyond loopback there is the operator's own act. govulncheckruns only in CI: the build sandbox cannot reachvuln.go.dev.- GitHub Actions and the build images are pinned to tags (
@v4,golang:1.26.10-alpine), not to SHAs/digests, so an upstream retag changes what CI runs. CI's Postgres service images are pinned by tag and digest (pgvector/pgvector:0.8.6-pg14@sha256:fb27…,…-pg16@sha256:ccc6…, the registry's index digests on 2026-10-18); Compose's is pinned by tag only. - Files: no quota.
store.GetFileitself takes only a file id; scoping is enforced bydocs.WriteFile(through a document in scope), and nothing yet stops another package calling the store directly (PR 4a'sTestImportBoundariespins who may importstore). Upload slots are held only while the client keeps up the read floor, but the floor is low: 16 clients each sending 64 KiB per 30 s (about 35 KiB/s in all) can hold every upload slot for the full 15 minutes. Uploads are buffered per extraction: two at a time (ingestSlots), each holding the file (≤ 64 MiB) plus a.docx's decompressed text parts (≤ 128 MiB) in the child, and about 60 MiB of server heap at the 16 MiB text cap (§ Files, memory of one ingest). Downloads use the same floor (64 KiB per 30 s, 15 minutes in all), so 4 clients reading just above it can hold all 4 read slots for 15 minutes, and ingest (which reads the stored file back) waits for them meanwhile. A stored file with no document is swept only at startup and only after an hour; a later PR that stores files of its own must teachSweepOrphanFilesabout them. - LAB rounds 3 and 4 (sweep order and skips, multi-part requirements, the crash journal, left-out evidence, raw deadlines, the parallel sweep, deviations, the coverage pass): the sweep's order is lexical, so a page that matters for a reason its words do not share can come late; a requirement's parts must be the document's own words, in order; an omission is confirmed absent by the paraphrase judge on the closest passage; the join asserts only what the figure judge says, and a figure the reader read unclearly is gated, not traced. The full lists: docs/reference.md § Limitations and docs/figures.md § Limitations.
- Documents, hybrid search and vision transcription (PRs 3a–3c): there is no OCR (scans are read by the vision model only); the vector leg is exact, so a query's cost grows with its scope's embedded chunks; a transcript is evidence of a lower class (capped, badged, gated when low). The full lists: docs/documents.md § Limitations.
- Heap-measuring tests share one test process.
TestDownloadBoundedused to sample the heap 300 ms after starting its downloads, which under-raceor CPU load caught the slot holders still fetching chunks (up to +31 MiB against its 24 MiB bound, r1 L-10): it now waits until all 4 holders are blocked writing and reads the live heap after a GC (+8 MiB in 9 runs, 4 of them beside 6 busy loops on 4 cores). It does not bound the transient peak while chunks are fetched (about 6 chunk-sized buffers per slot, measured in review). - Test schemas are dropped by
t.Cleanup; a test binary that is killed (SIGKILL, timeout) leaves itst_<hex>schema behind. Drop them withpsql -c "select 'drop schema '||nspname||' cascade;' from pg_namespace where nspname like 't\_%'" -At | psql. - Schema-per-test isolation cannot isolate Postgres extensions, which are database-wide:
storetestcreatesvectoronce per database (outside any test schema, cached per DSN) and puts its schema after the test's on thesearch_path, so a test's unqualified name that its schema lacks would resolve in that schema (publicby default) too. A future extension must follow the rule in CLAUDE.md. - No healthcheck for the biglaw container (distroless has no shell); Compose reports it "Up"
even when
/healthis 503. No access log; logs are text. /healthis unauthenticated and reports the version string. Images built by Compose report2.0.0-dev(no version is passed at build time).- Postgres is required, including on a Pi. There is no embedded-database mode.
- Model client (PR 2): behaviour against real endpoints other than the owner's bench and LAB
runs is unproven. Every call is charged, including on your own GPU (owner decision): an
Ollama model under an open-weights family name (
qwen2.5:14b) is charged at that family's hosted rate unlessBIGLAW_PRICESsets it to{"in": 0, "out": 0}, and a model with no row or anullone has an unknown cost the USD cap cannot count (only the call cap bounds it). The built-in rates are v1's early-2026 list prices, not re-verified for v2. The rest (gateway quirks, cache accounting,Retry-Afterforms,model.Fake's order): docs/reference.md § Limitations of the model client.
